特點:
配置專用自定心焊接卡盤;
夾裝工件快捷、簡便;
卡盤特殊設計,受熱不易卡死;
卡盤規(guī)格齊全,夾持范圍廣;
技術參數(shù):
型號 | 夾持范圍 |
C-65 | φ1-60mm |
D-125 | φ10-125mm |
D-160 | φ10-160mm |
D-200 | φ5-200mm |
D-300 | φ80-280mm |
D-400 | φ130-380mm |
D-500 | φ200-500mm |
D-600 | φ150-620mm |
D-700 | φ380-750mm |
DA-600 | φ85-615mm |
DA-1000 | φ85-1000mm |
Characteristics: D-series chucks are famous of the high accuracy, light weight structure, convenience and comfort in operation, great carrying capacity, so it will not be deformed and occur mergence of crash when the wielding temperature is very high.
Model | Clamp Range | Center hole's Dim |
D-200 | φ5-200mm | 65mm |
D-300 | φ80-280mm | 100mm |
D-400 | φ120-380mm | 170mm |
D-500 | φ200-500mm | 240mm |
D-600 | φ150-620mm | 365mm |
D-750 | φ380-750mm | 515mm |
