特點:
結構精巧,便于操作和移動;
精密導軌和絲杠傳動,運行精度高;
預留外圍配套設備的開關接口,可與周邊設備組合、聯動,實現環形焊縫和直線焊縫的自動焊接。
技術參數:
型號 | FZCZ-1515 |
輸入電源 | 3ph AC380V 50/60hz |
橫梁升降行程 | 1500mm |
橫梁伸縮行程 | 1500mm |
橫梁升降速度 | 700mm/min |
橫梁伸縮速度 | 200-1500mm |
橫梁驅動方式 | 變頻電機+滾珠絲杠調節 |
機頭水平微調行程 | 50mm |
機頭垂直微調行程 | 50mm |
機頭調節方式 | 手動調節 |
控制方式 | 手控盒控制 |
外形尺寸 | 2300*2200*620mm |
Characteristics:
This machine set the switch interface aside peripheral equipment, can be composed and linkage with welding positioner,
turning rolls and welding power, can achieve automatic welding for the girth and straight of the inside and the outside of the
cylinder or other metal structure.
Model | NHCZ-1515 |
Power Input | 3ph 380VAC 50/60Hz |
Beam Lift Itinerary | 1400mm |
Beam Stretch Itinerary | 1300mm |
Beam Lift Speed | 700mm/Min |
Beam Stretch Speed | 200--1500mm/Min |
Beam Drive Mode | Inverter Motor+ Ball Screw Drive |
Head Level Fine-tuning Itinerary | 100mm |
Head Vertical Fine-tuning Itinerary | 100mm |
Head Adjustment Mode | Electrically Adjust |
Control Mode | Hand Control Box Control |
H×L×B Over Dimension H×L×B | 2300×2200×620mm |
特點:
結構精巧,便于操作和移動;
精密導軌和絲杠傳動,運行精度高;
預留外圍配套設備的開關接口,可與周邊設備組合、聯動,實現環形焊縫和直線焊縫的自動焊接
Characteristics:
This machine set the switch interface aside peripheral equipment, can be composed and linkage with welding positioner,
turning rolls and welding power, can achieve automatic welding for the girth and straight of the inside and the outside of the
cylinder or other metal structure.
